Seamless Full Color LED Panel Stage Background LED Display Big Screen Hire 16 Bit

Seamless Full Color LED Panel Stage Background LED Display Big Screen Hire 16 Bit

  • High Light

    hd led screen

    ,

    hd led display

  • Module size
    288 X 288mm
  • Weight
    12Kg
  • Brightness
    900 - 1500 Nits
  • Color processing
    16bit
  • Refresh frequency
    ≥ 1200Hz
  • Best view distance
    ≥ 5m
  • Place of Origin
    Shenzhen ,China
  • Brand Name
    DDW
  • Certification
    CE/ROHS/FCC/UL/ISO/3C
  • Model Number
    DDW-HDP6000
  • Minimum Order Quantity
    Negotiable
  • Price
    Negotiable
  • Packaging Details
    Plywood or Flight Case
  • Delivery Time
    7-20 days
  • Payment Terms
    Bank T/T transfer, Western Union
  • Supply Ability
    6000sqm/month

Seamless Full Color LED Panel Stage Background LED Display Big Screen Hire 16 Bit


Seamless Full Color LED Panel Stage Background LED Display Big Screen Hire 16 Bit



 Seamless LED Video Wall is especially suitable for rental use. It's very lightweight and thin. Easy to assemble and dis-assemble. One person is able to hold a cabinet with one hand easily.



 >> Function and Technology characters



 1. Show all kinds of word, text, graph, pictures, flashes, video,2-dimension, 3-dimension cartoon and any other formats with your PC does synchronously.



 2. Different signal resources input are acceptable, such as TV, HCTV, S-video, NTSC/PAL,DVI, AVI, VGA, SDI, MOV, MPG, etc. We have three display modes as VGA+VIDE and VGA. There are also interfaces for Sound signal and video signal.



 3. 10 BIT grade grey control system and the color is over 16.7 millions, and the brightness, contrast, saturation, chromic can be adjusted by manual and sensor, whose scope is 256 grade



 4. Line-Double technology is adopted for the picture adjustment.

 5. Can be connected with PC and the web net and show the content, and also can be controlled remotely via VPM+ADSL.



 6. It can be used in advertisement, stage, stadium, exhibition, TV-Show,mansion video wall, shopping mall, banks, schools, bus station, airport, gym, market, factories, monitoring centers, hospitals, bars etc



 >> Product Description



Item Specification
Pixel Physical pixel pitch: 6 mm
Pixel configuration: 1R1PG1PB
Module Module resolution: 48 x 48pixel Module size: 288 x 288mm
Cabinet Cabinet resolution:96x96pixel Cabinet size:576 x 576x60mm
Cabinet :9216pixels Module Qty:4pcs=2(W)x2(H)
Material: Aluminum Weight:12Kg
Average power: 120W Max power consumption: 220W

Electricity

parameter

Brightness: 900 - 1500 nits
Brightness adjusted: 100 grade by software, or by Auto-optic induced
Color processing: 16bit
Display color: 280 trillion
Color temperature(k): 5000 — 9500 (choice by user)
Physical density: 27777 pixels/sqm
Whole display flatness: ≤ 1mm juncture
Best view distance: ≥ 5m
Best view angle: Horizontal ±80°, Vertical ±80°

Storage temperature: -35℃ ~ +85℃

Working temperature: -20℃ ~ +50℃

Driving method: Constant driving current Scan: 1/12
Refresh frequency: ≥ 1200Hz
Frame rate: ≥ 60Hz
Humidity(RH): ≤ 90~95%
Protection grade: IP64
Working Voltage: DC 5V
Power supply: AC 110 / 220V, 50/60Hz
Average power consumption:300w/sqm
Max power consumption: 600w/sqm
MTBF: 10, 000 hours
Screen lifetime: 100, 000 hours

Control

system

Signal interface: DVI
Communication distance: Internet cable: ≤120m Fiber cable: 1000m
Signal transfer mode: Pixels to pixels display synchronized



 >> seamless LED Video Wall



 1. Light weight: it can be loaded by one person, quick assembling, quick maintain, reduce. carrying, save costs.



 2.Thin cabinet:the thickness isonly10 CM, the space of the screen is small , and the entire screen will be more beautiful.



 3.Flat screen: smooth surface error is under 0.2cm, it can remove the mosaic phenomenon .effectively. The effect of the display will be more clear and exquisite.



 4. Quick dismounting: adopt fast locking structure connected, firm, quick, beautiful.



 5. Low release heat: low noise, low consumption, low cost, excellent thermal design and excellent thermal dispersion.
