10 Inch Flexible Led Panel Video Screen 10mm Pixel Pitch For Celebration Event
A LED screen is a video display which uses light-emitting diodes. An LED panel is a small display, or a component of a larger display or screen. They are typically used outdoors in store signs and billboards, and in recent years have also become commonly used in destination signs on public transport vehicles. LED panels are sometimes used as form of lighting, for the purpose of general illumination, task lighting, or even stage lighting rather than display.
1. we have the newest design of cabinet, ompared with the traditional cabinet,the Die-casting Aluminum cabinet has higher precision and strength , so p6 indoor led large screen can be used for many time withoutchanging cabinet shape .
2. the display is high cost-effective,you can use indoor,also can use outdoor at night,because it is waterproof.
3. Selection of high quality LED chips, it has wide angle, good flatness, strong anti-static, slow brightness degradation and high wavelength stability.
4. Seamless design:Gloshine exhibition patented kit design well controlled splice error between modules within ±0.1mm; easy to install, can be customized to any shape as requested.
5. Delicate picture:with the nonlinear correction technology creating a perfect display, vivid and various animation effect, smooth and realistic video effect.
| Pixel Pitch | 10mm |
| pixel Density | 10000dot/m2 |
| Pixel Configuration | SMD 3528(white/black), SMD3535, DIP346 |
| Cabinet material | Die-casting aluminum |
| Cabinet Size | 640mm*640mm*100mm |
| Cabinet Resolution | 64*64dot |
| Cabinet Weight | 7.5-20Kg(depending on different models) |
| Max Power Consumption | 1000W/m2 |
| Average Power Consumption | 500W/m2 |
| Drive Type | 1/4 Scan Constant Current |
| Driver IC | MBI5224 |
| Power supply | Meanwell 5V55A |
| Brightness | >5000nits |
| Color Temperature | 6500-9500K |
| Best Viewing Distance | 5m-30m |
| Cray Scale | 14bit |
| Color Scale | 36bit |
| Refresh Rate | >1200Hz |
| Best Viewing Angle | Horizontal 120°,Vertical 120° |
| Color Conformity | <4° |
| Control Mode | Synchronous control by computer |
| Conmmunication Distance | Cat5 network cable transmission:100meters;Multimode Optical |
| Malfunction Dot Rate | <1/10000 |
| Average No Failure Time | >10000H |
| Life-Span | >100000H |
| Working Voltage | AC220V/50HZ,AC110V/60HZ optional |
| Working Temperature | -20°C- +60°C |
| Working Humidity | 10%-90% |
>> Advantage
1. Waterproof design, completely outdoor use.
2. Easy for assembling and connection with the connector added.
3. High color uniformity and clear image can bring you a vivid audio visual effect.
4. Both front and rear access are available.
5. Good LED Chips, with large viewing angle, lowe power consumption and good color uniformity.
6. Easy for maintenance.
