P4mm Soft LED Module Indoor Led Screen Hire Customized Shaped Full Color For Wall
4.0mm pixel pitch, 1,000nits+ brightness, indoor rental or fixed applications
| P4mm Soft Indoor LED Display | |
| Pixel Pitch | 4mm (0.1575") |
| LED Brand | Nationstar* |
| Pixel Configuration | 1R1G1B |
| Pixel Density | 62,500 Pixels/m² |
| LED Module | Size: 240mmx120mm (9.45"x4.7244") |
| Resolution: 60*20 Pixels | |
| LED Cabinet | Size: Customized |
| Resolution: * pixels | |
| Material: Aluminum | |
| Weight: <6Kg (13.2 Lbs) | |
| Working Voltage | AC220V±10%; AC110V±10% |
| Power Consumption | Average 380W/m² / Max 850W/m² |
| Maximum Brightness | >800 cd/m² |
| Refresh Frequency | >3,840Hz/S |
| Change Frame Frequency | 50Hz~60Hz |
| Drive Mode | 1/16 Scanning |
| Total Colors | 281 Trillion Colors |
| Grade Level | RGB 65536 Grade |
| Best Viewing Distance | 4m~>100m (12ft~>300ft) |
| Best Viewing Angle | Horizontally 160° / Vertically 140° |
| Screen Lifetime | >100,000 hours |
| Protection Level | IP43 |
| Ambient Temperature | -40°C ~ 60°C (-30°F ~ 150°F) |
| Relative Humidity | 10%~90% |
| Control System* | Simple LED Video Control System or Advanced LED Video Processor |
| Input Signal | RF S-Video RGB RGBHV YUVYC etc. |
| Brightness Adjustment* | 256 levels of each colour (RGB) can be adjusted manually and 8 levels of each colour can be adjusted automatically. Optional control system: 256 levels of each colour can be adjusted 100% automatically. (8bit / 16bit / 18bit / 24bit) |
| Package Method* | Wooden Case / Flight Case |
| Warranty Date* | 2 Years (3 Years for Cree and Nichia) |
DDW P4mm Soft LED Module Indoor LED Display Customized Shaped LED Screen Wall Display is our new designed flexible indoor high-definition LED visualization product and special for the high-end market operators and users. The P4mm Soft LED Module Indoor LED Display Customized Shaped LED Screen Wall Display is a kind of unconventional indoor LED display, which adopts black SMD2121 LEDs from National star, it delivers more than 1000 nits brightness and the viewing distance is from 4m to 100m. By using MBI5153 or CH2153 driving ICs, the refresh of this P4mm Soft LED Module Indoor LED Display Customized Shaped LED Screen Wall Display can easy set more than 3840Hz.
The P4mm Soft LED Module Indoor LED Display Customized Shaped LED Screen Wall Display is becoming a kind of hot sale indoor LED screen unit, thanks to the freely curved capability, no matter for indoor rental or fixed installation, this P4mm Soft LED Module Indoor LED Display Customized Shaped LED Screen Wall Display supports customized and creative shape design for any of indoor video wall solutions.
By using our P4mm Soft LED Module Indoor LED Display Customized Shaped LED Screen Wall Display product, the rental events, broadcasting and advertising operators can easily mount a 2K, 4K, and even 8K large resolution indoor flexible LED video screen wall.
