Product description
1, lightweight, weighs 7 kg, single single hand, installation up easily;
2, ultra-thin - box by using magnesium aluminum zinc alloy die casting aluminum forming, high strength, high tenacity, high precision, it is not easy deformation, for transportation and effort;
3, high precision, size of the electrical and mechanical processing precision to 0.1 mm;
4, compatible, a new structure design, meet the requirements of hoisting, piled up, meet the requirements of indoor, outdoor,
5, fast - fast locking mechanism is used to connect body up and down or so, 10 seconds to complete the installation of an enclosure, installation of high precision;
6, reliable - strength, high hardness, good heat dissipation effect.
7, price, body weight, the installation cost is low; Housing low power consumption, low operation cost, so the price is very high.
P3.91 OUTDOOR P3.91 SMD 3IN1 TECHNICAL PARAMETERS
|
Unit Module |
Item | Parameter |
| Model Number | P3.91-16S | |
| Module size | 250mm*250mm | |
| Pixel pitch | 3.91mm | |
| Pixels Density | 65536 /m2 | |
| Pixel configuration | 1R1G1B | |
| LED Package mode | SMD1921 | |
| Pixel resolution | 64dots(W)*64 dots (H) | |
| Max Power | 40W | |
| Weight | 0.65kg | |
| Drive type | Constant drive | |
| Scan mode | 1/16scan | |
| Port type | HUB75-B | |
| Brightness of white balance | 3500cd/m2 |
|
LED Cabinet |
Dimension | 500mm*500mm |
| Monomer Module Number | 4pcs | |
| Power supply | 5V/40A*1pcs | |
| Pixel per cabinet | 128*128 | |
| Best viewing distance | 4M 20M | |
| Best viewing angle | 160 (W) 120 (H) | |
| Temperature |
storage:-35 +85 working:-20 +50 |
|
| Relative humidity | 10%-95% | |
| Thickness | 65mm |
|
Power |
Working voltage | AC110 220V 10% |
| Average Power consumption | <260W/ | |
| Max.Power consumption | <640W/ | |
| Current | <18mA(single LED) | |
|
Control system |
CPU | Pentium4 or above P4 |
| Operation system | XP/WIN7 | |
| Control method | Synchronization | |
|
Main technical parameter |
Driving device | Constant drive IC |
| Refresh frequency | >1920HZ | |
| Grey scale/colors |
16384 , 16.7M 16384gray level/16.7M colors |
|
| MTBF | >9000hours | |
| Power switch | Automatic switch | |
| Display Mode | 800*600/1024*768 |
Packaging
Carton box:It is the cheapest packing method for the led display,which is mainly for the small screen and short shipping distance.
Wooden case:Wooden case is only for one time using transportation. wooden case packing is the only way and the best way for packing since the low cost and same safety level for one timeusing.
Flight case: has wheels and handles which is for the rental use led display, to make the transportation be very convenient and protect the led display better..if your led display screen system is for the rental use, please choose the flight case for your led display screen.
