IP65 5000nits Outdoor Programmable Led Signs 10mm Pixels

IP65 5000nits Outdoor Programmable Led Signs 10mm Pixels

  • High Light

    IP65 Outdoor Programmable Led Signs

    ,

    5000nits Outdoor Programmable Led Signs

    ,

    10mm Pixels Waterproof LED Display

  • Usage
    Outdoor
  • Tube Chip Color
    Red,blue,green,white,mix Color
  • Display Function
    Graphics / Message
  • Pixels
    10mm
  • Brightness
    >5000cd/m2
  • Protection Level
    IP65
  • Led Chip
    Epistar/Slian
  • Cabinet Material
    Aluminum Alloy
  • Place of Origin
    Shenzhen ,China
  • Brand Name
    DDW
  • Certification
    CE/ROHS/FCC/UL/ISO/3C
  • Model Number
    DDW-OFCP1001
  • Minimum Order Quantity
    Negotiable
  • Price
    Negotiable
  • Packaging Details
    Plywood or Flight Case
  • Delivery Time
    7-20 days
  • Payment Terms
    Bank T/T transfer, Western Union

IP65 5000nits Outdoor Programmable Led Signs 10mm Pixels

Business Outdoor Programmable Led Signs Waterproof IP65 Red Green Color



 1. Single color by filling the whole of imported silica gel, which makes our products in water, antifreeze, superior high-temperature side.



 2. After a dustproof and waterproof tested to reach its target IP65.



 3. All modules are cross color enhancing, and the edge compression is strong, not deformation, the flatness of display cabinet will be better.



 4. The box with a sliding iron top, bottom chute, and optional locking device to fine-tune the gap and ensure seamless between the box. Please do not squeeze the entire screen which ensure good surface smoothness.



 5. Measured by the Shenzhen Institute of Quality Inspection Bureau U.S. core companies of the outdoor full color display for temperature impact test,the results showed that: outdoor full color display can use the power normally under the temperature at -25 °C to +75 °C.



 >>Technical Parameters for outdoor programmable led sign



Item Unit Parameter
Pixel Pitch mm 10
Pixel Density dots/sqm 10,000
Resolution of Module dots 16×16
Module Size mm 160×160
Led Package DIP 346 lamp
Pixel Configuration 1R
Chip Brand of LEDs Saman/Epistar/Silan
Brightness nits(cd/sq.m) 8,000
Scan Mode 1/4 Scan
Best View Distance m 10~75
Viewing Angle-Horizontal deg. 110
Viewing Angle-Vertical deg. 45
Max. Power Consumption W/sqm 790
Avg. Power Consumption W/sqm 270
Working Voltage AC 110~220V 50HZ(can select)
Waterproof Grade IP65
Refresh Rate Hz/S ≥480
Frame Rate Hz/S ≥ 60
Gray Scale 8192(13bits)
Display Function Text, news, advertising
Defective Dot Rate   <0.0001
Life Span hours 100,000
MTBF hours >10,000
Working Temperature °C -20 -- +60
Working Humidity 10%-95%RH
Control System VGA Synchronization
Quality Certificate CE,FCC,RoHS,CCC,ISO9001,ISO14001



IP65 5000nits Outdoor Programmable Led Signs 10mm Pixels 0
