1R1G1B 240W/sqm Outdoor LED Billboard For Football Perimeter

1R1G1B 240W/sqm Outdoor LED Billboard For Football Perimeter

  • 1R1G1B 240W/sqm Outdoor LED Billboard For Football Perimeter
  • 1R1G1B 240W/sqm Outdoor LED Billboard For Football Perimeter
  • 1R1G1B 240W/sqm Outdoor LED Billboard For Football Perimeter
  • 1R1G1B 240W/sqm Outdoor LED Billboard For Football Perimeter
1R1G1B 240W/sqm Outdoor LED Billboard For Football Perimeter
Product Details:
Place of Origin: Shenzhen ,China
Brand Name: DDW
Certification: CE/ROHS/FCC/UL/ISO/3C
Model Number: DDW-OBP1602
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Plywood or Flight Case
Delivery Time: 7-20 days
Payment Terms: Bank T/T transfer, Western Union
Supply Ability: 6000sqm/month
Contact Now
Detailed Product Description
Tube Chip Color: Full Color RGB: 1R1G1B
Module size: 256mm*128mm Refresh Rate: ≥1200Hz
Pitch size: 16mm Power consumption: 240W/sqm
High Light:

1R1G1B Outdoor LED Billboard

,

240W/Sqm Outdoor LED Billboard

,

8500nits Football Perimeter LED Display



High Definition Outdoor LED Billboard RGB RGB LED Display For Football Perimeter



 p16 outdoor Advertising LED football perimeter display , which is designed and continuously improved by our professional staff,is the most mature led video display of outdoor product series. IP65 rating outdoor led display board products that deliver high brightness and contrast ratio level with unequalled image quality weigh less,save power and withstand the adverse weather conditions.

 >> Feature

 (1) Multiplied file formats, such as AVI, MOV, MPG, DAT, VOB are comprehensive, and also we have three display mode as VGA+VIDE and VGA. There are also interfaces for Sound signal and video signal.
 (2) 4096 grade grey control system and the color is over 16.7 millions, and the brightness, contrast, saturation, chroma can be adjusted by manual and sensor, whose scope is 256 grade.
 (3) Show all kinds of word, text, graph, picture, video, 2-dimention, 3-dimention cartoon and other information with your PC does synchronously.
 (4) Line-Double technology is adopted for the picture adjustment.



p16 outdoor Advertising LED football perimeter display
Item Techinical Specifications
Pixel Pitch 16mm
LED Configuration DIP346 (1R1G1B)
Pixel Density 3906pixels/sq.m
Module Size 256mm*128mm
Module Resilution 16pixel*8pixel
Cabinet Size 1024mm*1024mm
Cabinet Resolution 64pixels*64pixels
Cabinet Material Iron/Aluminum
Cabinet weight 50kg/sqm or 40kg/sqm
Brightness 8500cd/sqm
Colour temperature 3500K-9500K(adjustable)
Viewing Angle H:110°/V:55°
Brightness Uniformity ≥97%
Brightness Adjustment Manual/Auto/Programmable
Ave. Power consumption 240 W/sqm
Max. Power consumption 800W/sqm
Input Voltage AC220V/50HZ or AC110V/60HZ (±10%)
Output Voltage 5V,40A
Best Viewing Distance 16m~200m
Contrast ratio 5000:1
Frame rate 50/60 Hz/sec
Refresh rate ≥1200Hz
Grey scale levels R(256bit) x G(256bit) x B(256bit)
Display Colors R(1024) x G(1024) x B(1024)
Protection Level IP65
Life-span 100,000 hours
MTBF 10,000 hours
Malfunction dot rate < 0.0001
Storage Temp/Humidity -30~+60℃/10~90%RH
Operating Temp/Humidity -20~+50℃/10~90%RH
Drive Mode Static contant current
Control System Synchronous/Asynchronous/Wifi/3G Wireless for choice
Input Signal RF,TV,RGB,S-VIDEO,PAL,DVI,HDMI,VGA,SDI,AVI,RGBHV,CVBS,etc
PC Operating System Microsoft Windows 7, 8, 98, 2000, XP and Vista


 1. Weather resistance:
 IP65 rating delivers best waterproof effect that ensures our product's stable broadcasting in harshest weather condition.

 2. World-class image quality:
 Strict system control and pixel to pixel correction make the image smooth and uniformity.

 3. System flexibility:
 Able to show a variety of content of video, animation, graphic and so on.

 4. Service facility:
 Modular design makes module individual and can fix easily without affecting others
1R1G1B 240W/sqm Outdoor LED Billboard For Football Perimeter 0
