1200cd/m2 SMD2020 P3.91mm Front Service Led Display 500x500mm

1200cd/m2 SMD2020 P3.91mm Front Service Led Display 500x500mm

  • 1200cd/m2 SMD2020 P3.91mm Front Service Led Display 500x500mm
  • 1200cd/m2 SMD2020 P3.91mm Front Service Led Display 500x500mm
1200cd/m2 SMD2020 P3.91mm Front Service Led Display 500x500mm
Product Details:
Place of Origin: China
Brand Name: DDW
Certification: CE/ROHS/FCC/UL/ISO/3C
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Delivery Time: 7-20 days
Payment Terms: Bank T/T transfer, Western Union
Supply Ability: 6000sqm/month
Contact Now
Detailed Product Description
Pixel Pitch: 3.91mm LED: SMD2020
Chip: Epistar IC: MBI5124
Refresh Rate: ≥2000HZ Brightness: ≥1200cd/m2
Cabinet Size: 500x500mm Warranty: 2 Years
High Light:

P3.91mm Front Service Led Display

,

SMD2020 Front Service Led Display

,

1200cd/M2 Full Color Led Board

Indoor rental led display 3.91mm lightweight front service cabinet size 500x500mm



Indoor front service way 3.91mm lightweight cabinet size 500x500mm rental led display



With unique and market-leading seamless technology, DDW 3.91mm effective control the video wall faceprecision down to 0.05mm. Not only 3.91mm, but also 4.81mm, 5.68mm, 6.25mm avaible. Moreover,DDWr have been developed front service way will be faster 90% than back service, as no need to remove screws.

1200cd/m2 SMD2020 P3.91mm Front Service Led Display 500x500mm 0

specification



pixel pitch 3.91mm
pixel density 65536 dots
configuration SMD2020 black
module size 250x250mm
panel dimension 500x500mm
panel weight 8kg
driving mode 1/16
refresh rate ≥2000HZ
brightness ≥1200cd/m²
power consumption avg:105w/panel max:300w/panel
grayscale 65536 level
viewing angle 140/140
lifespan 100000 hours at 50% brightness
operation temperature -40-+60
IP rating 3x
control system Novastar/Linsn





Quick details:



1. Die-casting aluminum structure can help to achieve an high precision.

2. Fast lock design enable us to do quick installation and dismantle.

3. Module design of different pixel pitch enable us to replace and not need to buy a new cabinet, which can be cost saving.

4. With excellent display quality, slim and light body.

5. It is used in stage events, exhibitions, bar, car show etc.





Advantages



1. Slim and light cabinet with 500x500mm.

2. Low brightness and high level delivery HD pictures.

3. Front service way.

4. Quick installation and dismantle.



1200cd/m2 SMD2020 P3.91mm Front Service Led Display 500x500mm 11200cd/m2 SMD2020 P3.91mm Front Service Led Display 500x500mm 2





Connection: Using Seetronic for main power/signal line and cabinet power/signal line

The cabinet was deigned to convenient connection, for faster installation.



Maintenance: Replace the modules, power supplier and receiving cards from back



Front service: The modules, power supplies and receiving cards can also be replaced from back, without

spending time on removing screws, maintenance will be 90% faster than back service.



If customer want to use laptop control, or with other device use together, the video processor will be necessary.
