P10 P16 Outdoor Full Color LED Display Led Advertising Panel 1 Year Warranty

Product Details

Place of Origin: Shenzhen ,China

Brand Name: DDW

Certification: CE/ROHS/FCC/UL/ISO/3C

Model Number: DDW-OFCP1609

Payment & Shipping Terms

Minimum Order Quantity: Negotiable

Price: Negotiable

Packaging Details: Plywood or Flight Case

Delivery Time: 7-20 days

Payment Terms: Bank T/T transfer, Western Union

Supply Ability: 6000sqm/month

Get Best Price
Product Details
Highlight:

outdoor fixed led display

,

outdoor full color led screen

Pixel Pitch(mm):
16mm
Pixel Configuration:
1R1G1B
Weight:
51kg
Module Size(mm):
256*256mm
Display Functio:
Video
IP Standard :
IP65
Pixel Pitch(mm):
16mm
Pixel Configuration:
1R1G1B
Weight:
51kg
Module Size(mm):
256*256mm
Display Functio:
Video
IP Standard :
IP65
Product Description

P10 P16 Outdoor Full Color LED Display Led Advertising Panel 1 Year Warranty



 >> Products characters



 1. High brightness which is adjustable to sufficiently meet the needs of various application environments.

 2. The raw material of all of the outdoor products including LED chips, mask, glue and steel cabinets have the ability of enduring high temperature and high humidity, and being
anti-UV, waterproof, anticorrosion and antirust.

 3. Every production process is well controlled and all of the electronic components are covered by 2mm Tri-Guard Lacquer to ensure no oxidation, no rusty and no moisture.
Five-Guard Lacquer will be used for special requirements

 4. All of the cabinets are tested by flush, shower and soaking, to ensure the waterproof grade in front side to be IP65 . .

 5.Display even after long-term use of perfect quality reproduction and enough brightness .



 1) Classification of item: P16 1R1G1B
 2) Working environment: Outdoor
 3) LED type: DIP1R1G1B
 4) Pixel composition: 1R1G1B
 5) Pixel pitch: 16.0mm
 6) Resolution of module: 16*16
 7) Pixel density: 3906dots/m2
 8) Module size: 256*256mm
 9) White balance brightness: ≥3500cd/m2
 10) Best view distance: 16~100m
 11) Driving mode: static constant current
 12) Module max power consumption: 38.4W
 13) Max power consumption: 1000W/sqm
 14) Resolution of cabinet: 48*48
 15) Dimension of cabinet: 768*768mm
 16) Weight of cabinet (waterproof): 51kg
 17) Viewing angle(H/V): 110°/50°
 18) Frame frequency: ≥60Hz
 19) Refresh frequency: ≥360Hz
 20) Gray scale: ≥16.7M (synchronal)
 21) Brightness adjustment mode: R, G, B 256 manual, 8 automatic
 22) Operating power source: AC220V ± 10% or AC110V ± 10%
 23) Working temperature: -20°C-50°C or -30°C-50°C
 24) MTBF: ≥10,000H
 25) Lifespan: ≥100,000H



 >> Advantage

 · Louvered-face and mask-face panels are avaiable.
 · The whole sign is separated into pieces for transportation.
 · Modular Design allows the sign to be built in various size.
 · LED module is sealed twice for good weather resistance.
 · Forced air ventilation and natural heat-dissipation system.

 · Easy access from double-layer weather-resistant rear doors.
