High Uniformity Outdoor Full Color LED Display Video Wall , P10 Led Screen

High Uniformity Outdoor Full Color LED Display Video Wall , P10 Led Screen

  • High Light

    outdoor fixed led display

    ,

    outdoor full color led screen

  • Pixel Pitch(mm)
    10mm
  • Power Consumption
    Average 200W/m²
  • Weight
    10kg/m²
  • Module Size(mm)
    160mm × 160mm (32 Pixels × 32 Pixels)
  • Display Functio
    Video
  • IP Standard
    IP65
  • Place of Origin
    Shenzhen ,China
  • Brand Name
    DDW
  • Certification
    CE/ROHS/FCC/UL/ISO/3C
  • Model Number
    DDW-OFCP1011
  • Minimum Order Quantity
    Negotiable
  • Price
    Negotiable
  • Packaging Details
    Plywood or Flight Case
  • Delivery Time
    7-20 days
  • Payment Terms
    Bank T/T transfer, Western Union
  • Supply Ability
    6000sqm/month

High Uniformity Outdoor Full Color LED Display Video Wall , P10 Led Screen


High Uniformity Outdoor Full Color LED Display Video Wall , P10 Led Screen



 P10 outdoor LED display adopts physical and virtual pixel technology which makes the picture more clear and vivid, no flicker and blind dots. The screen is manufactured in a waterproof and dustproof design so it can work very well in rain and sunshine. It can be assembled and disassembled very easy, and it is an ideal product for any kind advertisements.



 The outdoor led display characterized by perfect vivid image, super brightness, high refresh rate, long life span and stable work, and waterproof, etc.



 It is widely used in advertising, sports, industrial enterprise, transportation, stations, terminals, airports, construction, education system and other public places.



Pixel pitch10mm
Pixel density10000 pixels/m²
Power consumptionAverage 200W/m²
Module size160mm × 160mm (32 pixels × 32 pixels)
Single panel dimension0.768m(W) × 1.92m(H)
Pixel configurationTri-color RGB LEDs
Power supply

Power input: AC100V to 240V
Operating voltage: DC5V

Transparent rate5%
Display portDVI/HDMI
Display modeSynchronous to video source
Scan mode1/4
Screen resolution1024 × 768, max 1280 × 1024
Brightness1800/3600/6800nits
Viewing angle120°
Thickness11mm
Data refresh rate12000Hz
Colors16.7 million (R 256, G 256, B 256)
Ingress protectionIP43/IP54
Operating temperature-30°C ~ 60°C
Humidity10% ~ 90%
Weight10kg/m²
Hanging methodHanging type



>> Main advantages



 1. New mask design makes LED light almost zero reflection, which ensures the screen displaying effect;

 2. The cabinet of unit modules adopts to high-temperature spraying technology, the antirust function is greatly improved;



 3. Module surface flatness ± 0.2mm, the entire screen has good flatness;

 4. High uniformity display color;



 5. For improving the service life, PCB is made by wave soldering process with the green oxygen isolation layer, whichprevents the line of moisture and oxidation.



 6. Service efficiency of the screen switch power supply is increased substantially, which reduces power failure rate;

 7. Using fishbone bus line greatly reduces the contact problem;



 8. IP65 grade for high performance waterproof and dustproof capability;

 9. -25°C – 65°Cworking environment for outdoor display, adapted to the harsh environment.
