High Brightness Outdoor LED Billboard Advertising 8mm Pixel Nichia Or Epistar Chip

Place of Origin Shenzhen ,China
Brand Name DDW
Certification CE/ROHS/FCC/UL/ISO/3C
Model Number DDW-OBP8002
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Plywood or Flight Case
Delivery Time 7-20 days
Payment Terms Bank T/T transfer, Western Union
Supply Ability 6000sqm/month
Product Details
Pixel 8mm Module Size 256×128
LED Arrangement 1R1G1B Refresh Rate 240-1000HZ
Operating Temperature -40°C - 65°C Working Environment Outdoor
High Light

led screen billboard


led billboard advertising

Leave a Message
Product Description

High Brightness Outdoor LED Billboard Advertising 8mm Pixel Nichia Or Epistar Chip


 The indoor LED display can display colorful dynamic and static images in real time with perfect display effect. Thus, this LED display is the most significant display in all indoor full color screens.


 The LED display supports usual VGA and DVI tradational video signal, also specially supports HDMI video signal and so on. In addition, it can receive and display video programs, such as TV programs, VCD or DVD, living show etc.


 The products has high reliability, saturated and uniform color, hight brightness, low consumption, long service life and with wide angel sight. So the SMD full-color 3 in 1 indoor LED display is widely used in many indoor sites, such as show rooms, coffee house, hotel, stage and so on.


 >> Specification and Parameter


Technical DataModel PH8
Pixel Pitch 8mm
Physical Density(pixels/m²) 15625
LED Shape & Size SMD 3 in 1
LED Arrangement 1R1G1B
Module Size(mm) 256×128
Module Resolution 32*16
Drive Mode Dynamic 1/4Duty Constant Current
Brightness ≥5500cd/m²
Contrast(cd/m²) ≥2000:1
View Angle, 50% Brightness 140°/140°
Minimum View Distance 8m
Grey Scale 10bits/1024levels
Color Capacity 1.07billion
Maximum Power Consumption 1200W/m²
Ave.Power Consumption 320W/m²
Operation Power Source AC90-260V 50-60HZ
Frame Frequency 60-85HZ
Refresh Rate 240-1000HZ
Brightness Adjustment 0-100% 8 levels automatic
Gamma Correction -5.0-5.0
Correction Scale Level 16bits
Color Temperature 5000-9300K
Brightness Correction Pixels, Module, Cabinet Correction
Input Source Support Composite, S-Video,Component,VGA,DVI,HDMI,SDI, HD_SDI
Control Distance UTP CAT5E:100m;Multi-mode Fiber:50m;Single-mode Fiber:10km
Operating Temperature -40°C - 65°C
Operating Humidity 10-90%RH
Operating Life Span 100,000Hours
MTBF 5000 Hours
Protection Ratings IP65
Out of Control Rate 0.01%


 >> Advantage


 1. High Contrast:4000:1.


 2. First-class LED chip: Epistar from Taiwan


 3. Clear vivid image quality even in direct,full-on sunlight.


 4. Long-term Brightness capacity throughout product lifetime.

 5. Easy Installation & Using.


 6. Convenient Servicing.


 7. Source compatibility: CVBS,YC, YUV,RGB, DVI, SDI, HD-SDI, HDMI
