Product Details
Brand Name: DDW
Certification: CE/ROHS/FCC/UL/ISO/3C
Model Number: DDW-LEDIM
Payment & Shipping Terms
Minimum Order Quantity: 1~10
Packaging Details: Quality carton with full wood box packing/Flight case
Delivery Time: 7-20 days
Pixel Pitch: |
P1.57 |
LED Type: |
SMD1212 |
Refresh Rate: |
3840hz |
Cabinet Size: |
480*480mm |
Brightness: |
800-1000cd |
Module Size: |
240*120mm |
Pixel Pitch: |
P1.57 |
LED Type: |
SMD1212 |
Refresh Rate: |
3840hz |
Cabinet Size: |
480*480mm |
Brightness: |
800-1000cd |
Module Size: |
240*120mm |
Product features
– Low brightness and high gray technology, 5000:1, low power consumption
-3840Hz refresh rate, high dynamic picture display is real and natural, no smear
-Wide color gamut, uniform color, no rainbow effect, delicate and soft picture
-Metal heat dissipation, ultra-quiet fanless design
-Optional power supply and signal dual backup function
-Full front maintenance. High precision adjustment
-Die-cast aluminum design, seamless borderless, infinite splicing
The cabinet adopt cable-less design and HUB board design(integrated power board and receiving card) which can be maintenence in seconds, magnetic modules with front and rear maintenance
Allows to make curve video wall Inner outer arcs 15°,0°,-15° adjustable,right angle combination and other creative combinations
The thinner and lighter high-precision cabinet and interlocking function enable the installer to complete the installation very quickly and efficiently, such as direct wall mounting, hanging and stacking arc installation, thus saving time, energy and personnel costs.
| Pixel Pitch | P1.57 | P1.87 | P2.5 |
| Pixel Density | 401120 | 284444 | 160000 |
| LED Type | SMD1212 | SMD1515 | SMD2121 |
| Refresh Rate(Hz) | 3840 | ||
| Cabinet Size(mm) | 480*480 | ||
| Module Size(mm) | 240*120 | 240*240 | 240*240 |
| Module Resolution | 152*76 | 128*128 | 96*96 |
| Brightness(nits) | 800~1000 | ||
| Max Consumption(W/M) | 650 | ||
| Ave Consumption(W/M) | 195~300 | ||
| View Angle/Horizontal | 140 | ||
| View Angle/Vertical | 90 | ||
| Grey Scale(Bit) | ≥14 | ||
| Certificate | EMC,CE,ETL,FCC, CB | ||
