Slim Indoor Full Color Led Screen 4.8mm Pixel Pitch High Definition LED Display

Slim Indoor Full Color Led Screen 4.8mm Pixel Pitch High Definition LED Display

  • Slim Indoor Full Color Led Screen 4.8mm Pixel Pitch High Definition LED Display
  • Slim Indoor Full Color Led Screen 4.8mm Pixel Pitch High Definition LED Display
Slim Indoor Full Color Led Screen 4.8mm Pixel Pitch High Definition LED Display
Product Details:
Place of Origin: Shenzhen ,China
Brand Name: DDW
Certification: CE/ROHS/FCC/UL/ISO/3C
Model Number: DDW-IFCP4802
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Plywood or Flight Case
Delivery Time: 7-20 days
Payment Terms: Bank T/T transfer, Western Union
Supply Ability: 6000sqm/month
Contact Now
Detailed Product Description
Tube Chip Color: Full Color Protection Leve: IP65
Pixel Density: 43264 Pixel /m2 White balance Brightness: ≥800cd/ M2
Pixel Pitch: 48mm Pixel Type And Configuration: 1R1G1B
High Light:

indoor led display board

,

indoor fixed led display



Slim Indoor Full Color Led Screen 4.8mm Pixel Pitch High Definition LED Display



 >> Detailed Product Description



 PH4.8mm Slim Aluminum High Definition Fullcolor SMD Advertising Video Rental Indoor Led Display Screen



 1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
 2. Nice appearance and simple structures.
 3. Jointed correctly, being installed & dismounted by one person without tool.
 4. Humanized operating interface with breakdown indicator lights, easy to maintain.
 5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.



 >> Technicail Specification



Items Parameter
Pixel Pitch PH3.9mm PH4.8mm
Module Resolution(W*H) 128(W)*128(H) 104((W)*104(H)
Pixel Configuration 1R1G1B(in 3 n 1)
LED Encapsulation Black SMD 2121 Black SMD 3528
Pixel Density 65536 Pixel /m2 43264 Pixel /m2
Driving Method 1/16Scan 1/13Scan
Refresh Frequency ≥2880Hz ≥2880Hz
Driver IC Special constant current IC with high refresh rate & high grey scale
Grey Scale 14Bit(depending on the system and Configuration
Cabinet Size 500*500mm
White balance Brightness

≥800cd/ m2

≥800cd/ m2

≥800cd/ m2
Color Temperature 8000K±500(adjustable)
Viewing Angle Horizontal 140° Vetical 120°
Optimal Viewing Distance >4m >5m
Working Voltage AC 220V/110V ±10%
Module voltage DC4.2V

Max Power Consumption

/per module

100W/PCS 120W/PCS

Avg.Power Consumption

/per module

50W/PCS 60W/PCS
Lifetime 50000hours
Operating Temperature –10℃ ~ 65℃ –10℃ ~ 65℃
Net weight 3.5 Kg/pcs 3.5Kg/pcs


 >>Main Features

 1) LED: well-known brand, with wide viewing angle, high brightness, little attenuation,
good heat dissipation, and vivid colors.



 2) Driving IC: avoidable the defective phenomena, such as dark bright, virtual light and so on.


 3) Power supply: industrial-strength brand. The power t maximum power reserve of 20% the space,
the range of voltage fluctuation is less 5%, high stability.

Slim Indoor Full Color Led Screen 4.8mm Pixel Pitch High Definition LED Display 0
