IP40 SMD2525 6000nits Outdoor Rental Led Display For Events Show
Product Details:
| Place of Origin: | China |
| Brand Name: | DDW |
| Certification: | CE ROHS |
| Model Number: | P5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1square meter |
|---|---|
| Price: | Negotiable |
| Delivery Time: | 7-20 days |
| Payment Terms: | Bank T/T transfer, Western Union |
| Supply Ability: | 6000sqm/month |
|
Detail Information |
|||
| Pixel Pitch: | P3.91/P4.81/P5.95/P6.25mm | Leds: | Kinglight |
|---|---|---|---|
| Panel Material: | Die-Casting Aluminum | Controller: | Nova |
| Brightness: | >6000nits | Colours: | 281 Trillion |
| Highlight: | 6000nits Outdoor Rental Led Display,SMD2525 Outdoor Rental Led Display,IP40 Events Show Led Screen |
||
Product Description
Full Color High Brightness Outdoor Rental Led Display for Events Show
Full Color High Brightness Outdoor Rental Led Display Features
- Slim, light weight and quiet, easy to carry
- Deep black levels, contrast ratio 4000:1,The picture is clearer
- Operating temp/ humidity -20℃-60℃/ 10℃-60℃
Parameter
| Physical Pitch | 3.91mm | 4.81mm | 5.95mm | 6.25mm |
| Pixel Configuration | SMD1921 | SMD2525 | SMD2525 | SMD2727 |
| Pixel Density |
65,536 pixels/m² |
43,266 pixels/m² |
28,224 pixels/m² |
25,600 pixels/m² |
| Physical Resolution of Module(W*H)(mm) |
64*64/ 64*128
|
52*52/ 52*104
|
42*42/ 42*84
|
40*40/ 40*80
|
| Physical Resolution of Panel(W*H)(mm) |
128*128/ 128*256
|
104*104/ 104*208
|
84*84/ 84*168
|
80*80/ 80*160
|
| Module Dimensions(W*H)(mm) |
250*250/250*500
|
|||
| Panel Dimensions(mm) | 500*500*80/500*1000*80 | |||
| NO. of Modules Per Panel (W*H) | 2*2 | |||
| Panel Material | Die-Casting Aluminum | |||
| Colors | 281Trillion | |||
| Processing | 16 Bit | |||
| Single Cabinet Weight | 9/15kg/panel | |||
| Average Power Consumption | 75/150W/panel | |||
| Refresh Rate | >1,920 Hz | |||
| Brightness | >60,00 nits | |||
| Viewing Angle | H:160°/ V:140° | |||
| Expected Lifetime | 100,000 Hrs | |||
| Servicing | Front/Rear | |||
| IP Rating(Front/Rear) | IP40/IP21 | |||
| Max Stacking | 20/10 | |||
| Max Hanging | 20/10 | |||
Product details
Ultra light cabinet and have a great heat dissipation.
UI LCD monitoring display indicates the status.
Dual signal backup port.
Company
DDW a world class manufacturer of technologically advanced LED displays, focusing on high end professional customers among domestic and overseas markets. DDW is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.
DDW markets are among America, Europe, Middle East and Asia, all of our products are certificated by RoHS,CCC,CE,FCC,ETL,UL. Standing firmly by quality, winning firmly by proficient, in the past years of development.
After Sale Service
Pre-producing
- Get complete requirements of clients.
- To do a thorough analysis.
- Offer a most reasonable and scientific solution.
- Customized design.
In producing
- Producing progress updating for clients
- Particular Installation CAD and Design Diagram for clients.
After service
- 2 years free maintenance
- 7 days a week, 24 hours a day for 5 years on-line service for any technical support for any customers
- Free training for customers in factory
- Local Partner Installation Service
