IP65 Front Service LED Display P8 LED Outdoor Advertising Screens AC110V - 220V

IP65 Front Service LED Display P8 LED Outdoor Advertising Screens AC110V - 220V

  • IP65 Front Service LED Display P8 LED Outdoor Advertising Screens AC110V - 220V
  • IP65 Front Service LED Display P8 LED Outdoor Advertising Screens AC110V - 220V
IP65 Front Service LED Display P8 LED Outdoor Advertising Screens AC110V - 220V
Product Details:
Place of Origin: Shenzhen ,China
Brand Name: DDW
Certification: CE/ROHS/FCC/UL/ISO/3C
Model Number: DDW-OFSP8000
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Plywood or Flight Case
Delivery Time: 7-20 days
Payment Terms: Bank T/T transfer, Western Union
Supply Ability: 6000sqm/month
Contact Now
Detailed Product Description
Module Size: 320*320mm Pixels: 8mm
Protection Grade: IP65 Brightness: >5500nits
Viewing Angle: 140°/140° Working Temperature: -20℃ - +60℃
High Light:

front maintenance led display

,

front service led sign


IP65 Front Service LED Display P8 LED Outdoor Advertising Screens AC110V - 220V



 >> Description



 1. Outdoor pixel pitch 8mm; Also 6.67mm and 10mm are optional. LED modules size is 320x320mm.

 2. Ingress Protection IP65 level to protect the LED screen from harsh outdoor environment

 3. Brightness can reach as high as 6000nits to be visible clearly even in sunlight.
 4. Reliable quality of all components to ensure the long life span to 100000H
 5. Front service design to save structure cost and labor cost
 6. High refresh rate 1920Hz and stable performance;



Pixel Pitch 8mm
Pixel Density 15,625dos/sqm
LED Configuration SMD3535
Module Size 320*320mm
Module Resolution 40*40 dots
Cabinet Size 960*960mm
Cabinet Resolution 120*120dot
Brightness >5500nits
Refresh Rate >1920hz
Viewing Distance 10-300m
Power Input AC110V - 220V ±15%, 50HZ
Max Power Consumption 680W/sqm
Ave. Power Consumption 195W/sqm
Working Temperature -20℃ - +60℃
Lifespan >100,000 Hours
Operating Humidity 10% - 95%
Input Source All Format (AVI, MPEG,VOB, RM, etc)


 >> Description

 1, Maintenance can be conducted from either front or rear side.
This is front maintenance steel cabinet with frame and hydraulic lever, easy to maintain from the front;
 2, It can be installed without taking the space for maintenance channel into consideration, thus improving your work efficiency.
 3, Long-term Brightness:6000-nit brightness(for outdoor full colour) throughout product lifetime of the LED display
 4, It Controlled with PC by synchronization, with high refresh rate;



 >> After Sales Service


 1. 24-hour hotline service, including counselling and technical guidance.
 2. On-line service.
 3. Failure maintenance of LED panels.
 4. Free professional technical training
 5. Paid software upgrade.
 6. Warranty service: Each of our LED display products comes with at least one years warranty and a lifetime maintenance
 7. Engineering technical service.



 >> Technical support


 1. Installation and Maintain Manual

 2. LED display system connection diagram

 3. Data wire connection diagram

 4. Power supply wire connection diagram

 5. multi-language software Guidance
