1R1G1B P6 HD LED Video Wall Full Color RGB Stage Background Screen Rental

1R1G1B P6 HD LED Video Wall Full Color RGB Stage Background Screen Rental

  • 1R1G1B P6 HD LED Video Wall Full Color RGB Stage Background Screen Rental
  • 1R1G1B P6 HD LED Video Wall Full Color RGB Stage Background Screen Rental
1R1G1B P6 HD LED Video Wall Full Color RGB Stage Background Screen Rental
Product Details:
Place of Origin: Shenzhen ,China
Brand Name: DDW
Certification: CE/ROHS/FCC/UL/ISO/3C
Model Number: DDW-HDP6002
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Plywood or Flight Case
Delivery Time: 7-20 days
Payment Terms: Bank T/T transfer, Western Union
Supply Ability: 6000sqm/month
Contact Now
Detailed Product Description
 Cabinet Weight: 19Kg Brightness: 2000nit
Tube Chip Color: Full Color LED Composition: 1R1G1B
Pixels: 6mm Viewing Distance: 11m
High Light:

hd led display

,

high definition led display


1R1G1B P6 HD LED Video Wall Full Color RGB Stage Background Screen Rental



 As a high-tech joint-stock enterprise, we have the strongest R&D team. With our advanced R&D team, we have already researched and developed LED fluorescent tubes, LED bulbs, LED spotlights, LED street lights, LED downlights, LED panel lights, LED grille lights, LED screens, LED modules and others, totally more than twenty series and thousands of varieties. Our products are widely applied in commercial shops, shopping malls, offices, hotels, conference rooms, museums and other public facilities. With unique exterior structural design capability, continuous quality improvement capability and quick respond to market demands,



 >> Feature

 · White Balance: D50 to D93
 · Extremely Thin Design

 · Brightness: 2000nits(adjustable)

 · 1R1G1B SMD Pixel Configuration

 · Max Power Consumption:15W

 · High Viewing Angle

 · DC 5V Voltage Input
 · High Refresh Rate Performance



Parameter Unit Value
Pixel pitch mm 6
Panel brightness nit 2000
Viewing angle - Horizontal deg. 140
Viewing angle - Vertical deg. 140
Cabinet Weight kg 19
Cabinet Width mm 1024
Cabinet height mm 768
Cabinet depth mm 185
Cabinet area sq. m. 0.79
Cabinet material   Aluminium
Aspect ratio   6:5
Ingress Protection (Front/Rear) IP IP65/IP21
Operating temperature range deg. C -20 to 50
Operating Humidity range HR 10% to 90%
Pixel type and configuration R/G/B 1,1,1
Pixel pitch mm 10.667
Pixel matrix per cabinet   96*72
Pixels per cabinet   6912
Lines per meter   94
Pixels per sq. meter   8789
LEDs per sq. meter   26367
Recommended minimum viewing distance m 11
Colours   1.07Billion
Gray scale Levels 1024 levels per colour
Brightness control Levels 100
Digital processing bit 10
Frame rate Hertz 60
Display refresh rate Hertz ≥400
Scan mode   Static
Input voltage VAC 110 to 240
Input power frequency Hertz 50 or 60
Input power (max/avg) Watts per sq.m 600/250



 >> Characteristics for RGB Led Display

 · easily upgrade size of sign.

 · user friendly computer system .
 · approximate 3D image quality.

 · Fast and easy to assemble and dismantle.

 · Wide viewing angle ,excellent white color balance.

 · High grayscale with perfect visual performance.
 · High reliability and long lifespan over 100,000hrs.
