Super Slim High Definition Video Screen P11mm Full Color LED Display Cabinet

Place of Origin Shenzhen ,China
Brand Name DDW
Certification CE/ROHS/FCC/UL/ISO/3C
Model Number DDW-HDP1001
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Plywood or Flight Case
Delivery Time 7-20 days
Payment Terms Bank T/T transfer, Western Union
Supply Ability 6000sqm/month
Product Details
Modules Size  240 * 320 Mm Brightness ≥ 1200cd/M2
Tube Chip Color Full Color LED Composition 1R1G1B
Pixels 1mm Cabinet Weight  9 Kg
High Light

hd led display

,

high definition led display

Leave a Message
Product Description

Super Slim High Definition Video Screen P11mm Full Color LED Display Cabinet

 The P10 LED Display Wallcan be suspended or vertically mounted as different demands from leasing or purchasing users. Convenient design on the connection structure, two cabinets can be connected easily in 10 second without any tools.



 >> Description



 1: Ultra-thin design with high permeability, reduce the weight of the display screen to the limit.

 2: Adapt to each pixel, each module, each box and the entire screen, point by point correction, Prefect white balance.

 3: The unique design of the drive circuit, so that the refresh rate easily reach to 3000HZ.

 4: Use the outdoor bright LED lamp, the led display can show a wider viewing angle, great color mixing, making the displaying color more vivid.

 5: The rugged aluminum housing, durable and light weight.

 6: IP66 protection design, support for long-term outdoor use and can be resistant.

 7: The cabinet is designed using a new type of scalability hanging style, quick and easy installation and maintenance more convenient.

 8. Good heat dissipation.


 >> specifications



Specification

P10

Item 1 ---LED Chip



Brand

Epistar ,Opto , Cree , Nichia

Country of Origin

Taiwan. United States. Japan

Span life

≥ 100,000 Hrs

Item 2--- Modules



Pixel Pitch

PH 10

LED configuration

SMD 3528(3 IN 1)

LED Composition

1R1G1B

Modules size

240 (L) mm * 320 (H) mm

Driving IC

MBI 5024/5041

Driving Method

Constant Current / (1/4 scan)

Item 3--- Cabinet



Cabinet size

480 (L) mm * 960 (H) mm

Cabinet Material

wire drawing aluminum cabinet

Installation Method

Fix / Hanging / Rental

Cabinet weight

9 Kg

Item 4--- Display screen



Brightness

≥ 1200cd/M2

Viewing Angle



Refresh Rate

≥800 Hz

Fresh Requency

≥60Hz

Input Voltage

AC220V/50Hz or AC110V/60Hz

Power Consumption

Max.:450 W/M2 Average:120W/M2

Front and Back protective Grade



Signal Output

HDMI DVI VGA RGBHV PbPr (HDTV)

Signal Connection

Video TB SDI

Controlling System

Linsn/ Colorlight / Nova/ DB Start …

Operating System

Windows98/me/2000/NT/XP Window7 ,Vistar



 >> Competitive Advantage


 1. The green light and red light on the back of the cabinet makes it easier to detect the problem on signal and power source, save a lot of trouble for you on maintenance.



 2. Nature heat dissipation without using any specific equipment, allow the working of the screen more quiet.


 3. Super-slim cabinet design, aluminum alloy cabinet makes the screen extremely lightweight, perfect for stage decoration usage.



 4. The flatness of the display is greatly improved by its high-precision processing technology, one card for one cabinet design, highly improve the refresh rate.
