High Refresh P1.667 LED Video Wall TV Screens , High Definition LED Display

High Refresh P1.667 LED Video Wall TV Screens , High Definition LED Display

  • High Light

    small pixel pitch led screen

    ,

    high brightness led screen

  • Module Size
    200*300mm
  • Pixels
    1.667mm
  • Module Resolution
    120*180dot
  • Cabinet Wegiht
    4.65kg/pc
  • Operating Humidity
    10% - 95%
  • Viewing Distance
    1.6-60m
  • Place of Origin
    Shenzhen ,China
  • Brand Name
    DDW
  • Certification
    CE/ROHS/FCC/UL/ISO/3C
  • Model Number
    DDW-S3P1877
  • Minimum Order Quantity
    Negotiable
  • Price
    Negotiable
  • Packaging Details
    Plywood or Flight Case
  • Delivery Time
    7-20 days
  • Payment Terms
    Bank T/T transfer, Western Union
  • Supply Ability
    6000sqm/month

High Refresh P1.667 LED Video Wall TV Screens , High Definition LED Display


High Refresh P1.667 LED Video Wall TV Screens , High Definition LED Display



 >> Features



 1. 3840hz High refresh led screen smoothly like HD TV Screen
 2. Black nationstar led lamp to improve the contrast ratio to be 4000:1
 3. Power supply and Signal Dual backup to ensure led screen working stable
 4. Nationstar led lamp with high quality 4Layer PCB materials to ensure the lifespan
 5. Same Cabinet can be P1.56, p1.66, p1.923



Item parameter
Pixel Pitch PH1.667mm
Pixel Density 360.000dos/sqm
LED Package Black faceSMD1010
Module Size 200*300mm
Module Resolution 120*180dot
Cabinet Size 400*300mm
Cabinet Resolution 240*180dot
Cabinet Wegiht 4.65kg/pc
Viewing Angle 140°/140°
Viewing Distance 1.6-60m
Power Input AC110V - 220V ±15%, 50HZ
Max Power Consumption 835W/sqm
Ave. Power Consumption 265W/sqm
Working Temperature -20℃ - +60℃
Input Source All Format (HDMI, SDI, DVI,AVI, MPEG,VOB, RM, etc)



 >> Cabinet

 Standard Aluminum cabinet design
 Cabinet Weight: 7.5kg
 Cabinet dimension:400*300mm
 Easy to installation and transportation

 >> Module

 High Stability Nationstar lamp
 High efficient LED chip,low power consumption
 Less heat dissipation make
 Guarantees a reliable performance
 Excellent color reproduction capability

 >> After-sale service

 1. Lifetime free maintenance and upgrade.
 2. Complaint responds period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
 3. Customer satisfaction tracking report.
 4. Free technician training.
