Advertising Outdoor LED Display Screen P6 Front / Rear Service Fixed Installation

Advertising Outdoor LED Display Screen P6 Front / Rear Service Fixed Installation

  • Advertising Outdoor LED Display Screen P6 Front / Rear Service Fixed Installation
  • Advertising Outdoor LED Display Screen P6 Front / Rear Service Fixed Installation
Advertising Outdoor LED Display Screen P6 Front / Rear Service Fixed Installation
Product Details:
Place of Origin: Shenzhen ,China
Brand Name: DDW
Certification: CE/ROHS/FCC/UL/ISO/3C
Model Number: DDW-OFSP6000
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Plywood or Flight Case
Delivery Time: 7-20 days
Payment Terms: Bank T/T transfer, Western Union
Supply Ability: 6000sqm/month
Contact Now
Detailed Product Description
Module Size: 320*320mm Pixels: 6mm
Protection Grade: IP65 Brightness: >6000nits
Viewing Angle: 140°/140° Refresh Rate: >3840hz
High Light:

front service led screen

,

front service led sign


Advertising Outdoor LED Display Screen P6 Front / Rear Service Fixed Installation



 >> Features


 1. P6 P8 and P10 Types is optional, all LED modules size is 320x320mm.

 2. Outdoor IP65 waterproof level to protect it from harsh outdoor environment

 3. Brightness can get 6000nits to face the sunshine.
 4. Reliable quality all components to ensure the long life span to 100000H
 5. Front service design to save structure cost and labor cost
 6. High refresh rate 3840Hz and stable performance

Pixel Pitch 6mm
Pixel Density 22956 dos/sqm
LED Configuration SMD2727
Module Size 320*320mm
Module Resolution 48*48 dots
Cabinet Size 960*960mm
Cabinet Resolution 144*144dot
Brightness >6000nits
Refresh Rate >3840hz
Viewing Distance 6-100m
Power Input AC110V - 220V ±15%, 50HZ
Max Power Consumption 850W/sqm
Ave. Power Consumptio 320W/sqm
Working Temperature -20℃ - +60℃
Lifespan >100,000 Hours
Operating Humidity 10% - 95%
Input Source All Format (AVI, MPEG,VOB, RM, etc)


 >> Description

 1, Maintenance can be conducted from either front or rear side.
This is front maintenance steel cabinet with frame and hydraulic lever, easy to maintain from front;
 2, It can be installed without taking the space for maintenance channel into consideration, thus improving your work efficiency.
 3, Long-term Brightness:6000-nit brightness(for outdoor full color) throughout product lifetime of the LED display
 4, It Controlled with PC by synchronization, with high refresh rate;
 5, 1% spare parts provided for customers to replace defective ones in the future.



 >> Application

 Stock exchange centers, customs, stadiums, studio, shopping malls, railways, airports, harbors,

high way, commercial advertising, Stadium perimeter, mobile media, bus station, schools,

telecommunications,entertainment events, business establishments, such as banks, etc;


 >> Technical support



 1. Installation and Maintain Manual

 2. LED display system connection diagram

 3. Data wire connection diagram

 4. Power supply wire connection diagram

 5. multi-language software Guidance
