Pitch 6.25 Mm Indoor Rental LED Display System Full Color Slim Light Weight

Place of Origin Shenzhen ,China
Brand Name DDW
Certification CE/ROHS/FCC/UL/ISO/3C
Model Number DDW-IRTP6000
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Plywood or Flight Case
Delivery Time 7-20 days
Payment Terms Bank T/T transfer, Western Union
Supply Ability 6000sqm/month
Product Details
Module size 288 X 288mm Brightness 900 - 1500 Nits
Pixel configuration 1R1PG1PB Pixel Pitch 6mm
Weight 12Kg Color processing 16bit
High Light

rent led screen

,

rent led display

Leave a Message
Product Description



Pitch 6.25 Mm Indoor Rental LED Display System Full Color Slim Light Weight



 indoor Rental LED Display is especially suitable for rental use. It's very lightweight and thin. Easy to assemble and dis-assemble. One person is able to hold a cabinet with one hand easily.



 >> Main features of indoor Rental LED Display



 1. Light weight

 2. High resolution images

 3. Competitive prices, reliable quality;

 4. High contrast ratio which ensures vivid images;

 5. Low power consumption, environmentally friendly;

 6. Customizable for various sizes;

 7. Compatible software: S-Video, Composite, YUV, RBG, SDI, HKSDI, Data SVI up to SXGA;

 8. Excellent after-sales service, warranty of one years;

 9. CE, ROHS, ISO certificate


 >> Product Description



Item Specification
Pixel Physical pixel pitch: 6 mm
Pixel configuration: 1R1PG1PB
Module Module resolution: 48 x 48pixel Module size: 288 x 288mm
Cabinet Cabinet resolution:96x96pixel Cabinet size:576 x 576x60mm
Cabinet :9216pixels Module Qty:4pcs=2(W)x2(H)
Material: Aluminum Weight: 12Kg
Average power: 120W Max power consumption: 220W

Electricity

parameter

Brightness: 900 - 1500 nits
Brightness adjusted: 100 grade by software, or by Auto-optic induced
Color processing: 16bit
Display color: 280 trillion
Color temperature(k): 5000 — 9500 (choice by user)
Physical density: 27777 pixels/sqm
Whole display flatness: ≤ 1mm juncture
Best view distance: ≥ 5m
Best view angle: Horizontal ±80°, Vertical ±80°

Storage temperature: -35℃ ~ +85℃

Working temperature: -20℃ ~ +50℃

Driving method: Constant driving current Scan: 1/12
Refresh frequency: ≥ 1200Hz
Frame rate: ≥ 60Hz
Humidity(RH): ≤ 90~95%
Protection grade: IP64
Working Voltage: DC 5V
Power supply: AC 110 / 220V, 50/60Hz
Average power consumption:300w/sqm
Max power consumption: 600w/sqm
MTBF: 10, 000 hours
Screen lifetime: 100, 000 hours

Control

system

Signal interface: DVI
Communication distance: Internet cable: ≤120m Fiber cable: 1000m
Signal transfer mode: Pixels to pixels display synchronized



>> Advantage



 1. Light weight: it can be loaded by one person, quick assembling, quick maintain, reduce. carrying, save costs.



 2.Thin cabinet:the thickness isonly10 CM, the space of the screen is small , and the entire screen will be more beautiful.



 3.Flat screen: smooth surface error is under 0.2cm, it can remove the mosaic phenomenon .effectively. The effect of the display will be more clear and exquisite.



 4. Quick dismounting: adopt fast locking structure connected, firm, quick, beautiful.



 5. Low release heat: low noise, low consumption, low cost, excellent thermal design and excellent thermal dispersion.
