P5 Indoor LED Video Wall Rental Adjustable Brightness For Events / Theater Stage

P5 Indoor LED Video Wall Rental Adjustable Brightness For Events / Theater Stage

  • High Light

    rent led screen

    ,

    rent led display

  • Usage
    Indoor
  • Brightness
    ≥3500cd/m2
  • Viewing Distance
    5 - 15 Meters
  • Pixel Pitch
    5mm
  • Weight
    30Kg
  • Pixel Configuration
    1R1G1B
  • Place of Origin
    Shenzhen ,China
  • Brand Name
    DDW
  • Certification
    CE/ROHS/FCC/UL/ISO/3C
  • Model Number
    DDW-IRTP5000
  • Minimum Order Quantity
    Negotiable
  • Price
    Negotiable
  • Packaging Details
    Plywood or Flight Case
  • Delivery Time
    7-20 days
  • Payment Terms
    Bank T/T transfer, Western Union
  • Supply Ability
    6000sqm/month

P5 Indoor LED Video Wall Rental Adjustable Brightness For Events / Theater Stage


P5 Indoor LED Video Wall Rental Adjustable Brightness For Events / Theater Stage



 Indoor Rental LED Display Screen could be used in indoor environment such as municipal mansion, enterprise hall, show room, cinema, stage, with various real-time signal sources and the SMD
encapsulation technology, its purpose is to play the important news or events or TV program .

 1) High and adjustable brightness can meet the demands of the changing requirement of Customer in different environments.
 2) No mosaic due to excellent flatness and nice uniformity of light-emitting.
 3) Wide viewing angles and the horizontal angle can reach 140° , The images effect will not change largely in the range.
 4) High density make the images softer and vivider.
 5) Single-lamp maintenance with low cost.
 6) Good heat dissipation capability because of the unique design of vent fan (liking shutter).
 7) Environmental-friendly and energy-saving.



Pixel Information Pixel Pitch 5mm
Pixel Density 40000 Pixels/m2
Pixel Configuration 1R1G1B
LED Wavelength Red: 615 nm - 635 nm
Green: 520 nm - 535 nm
Blue: 465 nm - 475 nm
LED Module Module Size(mm) 160 (Width) × 160 (Height)
Module Resolution 32(Width) × 32 (Height)
Cabinet Cabinet Size(mm) 640 (Width) ×640(Height)
Cabinet Resolution 128 (Width) × 128 (Height)
Total QYT Module Per Cabinet 4 (Width) ×4(Height)
Cabinet Weight 30kg/m2
Cabinet Material Die-casting Aluminum LED Display
Power Input Voltage 100-240V AC, 50/60Hz
Max Power Consumption 1100 Watt/m2
Avg. Power Consumption 650 Watt/m2
  Brightness ≥3500cd/m2
Brightness Uniformity Luminance Discrepancy < 5%
Best Viewing Angle Horizontal:140°,Vertical:70°
Viewing Distance 5 - 15 meters
Ambint Conditions Temperature Range Working:-20deg. to +60deg
Operating Humidity 10%90%RH
Ingression Protection Grade IP30
Processing Scanning Mode 1/8 scanning
Refresh Frequency 600-1200HZ, Adjustable(depends on control system)
Signal Input DVI, Composite Video for Live Video
Supported Networking Through LAN/WAN, RS 232/RS485
Controller Linsn or Nova



 Advantage

 · 1. Wide application: it can be used for any rental application of stage show: such as main rental led display, side screen, floor screen, arc screen stage design etc.
 · 2. Easy and Fast: for both installation and dismantling, without any tools, it takes only 10 seconds to assembly, hanging, pile up and fix installation available.
 · 3. High structure performance: easy connection of each components, modules and HUB card without flat cables, modules and systems without power cable.

 · 4. Both indoor and outdoor series are compatible, outdoor SMD and DIP screen with IP65 weatherproof level, so it can be used normally in rainy days.

 · 5. Floor led screen can bear 1 ton weight, IP65 weatherproof level.
