Outdoor Double Side Front Access LED Display HD P4 With Front Opening Cabinet

Place of Origin Shenzhen ,China
Brand Name DDW
Certification CE/ROHS/FCC/UL/ISO/3C
Model Number DDW-OFSP4001
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Plywood or Flight Case
Delivery Time 7-20 days
Payment Terms Bank T/T transfer, Western Union
Supply Ability 6000sqm/month
Product Details
Module Size 256*128mm Pixels 4mm
Protection Grade IP65 Brightness >5000nits
Viewing Angle 140°/140° Cabinet Weight 45kg/sq.m
High Light

front service led screen


front maintenance led display

Leave a Message
Product Description

Outdoor Double Side Front Access LED Display HD P4 With Front Opening Cabinet


 >> Features

 1. LED display size is cutomized, outdoor P3, P4,P5,P6,P8,P10 is optional.

 2. Double Side LED display attract more people eye's watch advertising.

 3. Front access design makes maintenance is easier.

 4. Remote control don't need computer, controlled by 4G,USB,Wifi etc.

 >> Specification


Item parameters
Pixel Pitch 4mm
Pixel Density 62500 dos/sqm
LED Package SMD1921
Module Size 256*128mm
Module Resolution 64*32dot
Cabinet Size 768*640mm
Cabinet Resolution 192*160dot
Cabinet Materials aluminum
Cabinet Wegiht 45kg/sq.m
Brightness >5000nits
Refresh Rate >1920hz
Viewing Angle 140°/140°
Max Power Consumption 720W/sqm
Ave. Power Consumptio 270W/sqm
Life Span >100,000 Hours
Operating Humidity 10% - 95%
Certificate CE,ROHS,FCC,ACMA
Control method Wifi, USB,LAN,3G,4G

 >> Description

 1. Usage : Different outdoor environment,poles,shopping mall, buildings,trains,airports etc
 2. Installation : Wall-mounted, pole support. hanging etc
 3. Control : Contolled by your phone,Pad,PC.
 4. Connection : Connected to your computer,Camera or own equipment.
 5. Maintenance: Enough Free spare parts for replacement.,Front service


 >> After Sales Service

 1. 1 years warranty
 2. Free factory training
 3. 24/7H online support
 4. Lifetime free repair and technical support
Outdoor Double Side Front Access LED Display HD P4 With Front Opening Cabinet 0
