10mm Pixels Outdoor LED Display Screen Modular Design For Shopping Mall

10mm Pixels Outdoor LED Display Screen Modular Design For Shopping Mall

  • High Light

    front service led screen

    ,

    front service led sign

  • Module Size
    320*320mm
  • Pixels
    10mm
  • Protection Grade
    IP65
  • Brightness
    >5500nits
  • Viewing Distance
    10-100m
  • Working Temperature
    -20℃ - +60℃
  • Place of Origin
    Shenzhen ,China
  • Brand Name
    DDW
  • Certification
    CE/ROHS/FCC/UL/ISO/3C
  • Model Number
    DDW-OFSP1004
  • Minimum Order Quantity
    Negotiable
  • Price
    Negotiable
  • Packaging Details
    Plywood or Flight Case
  • Delivery Time
    7-20 days
  • Payment Terms
    Bank T/T transfer, Western Union
  • Supply Ability
    6000sqm/month

10mm Pixels Outdoor LED Display Screen Modular Design For Shopping Mall


10mm Pixels Outdoor LED Display Screen Modular Design For Shopping Mall



 >> Features



 1) High Definition and can be adjusted, can show DVD, TV, Dynamic images, VCRs,

graphs, letters and animations for 24 hours. Sharp, colorful, synchronized with a computer monitor.

Waterproof, Sun-screen, antistatic, damp proof, anti-freeze, anti-thundering etc.


 2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light.

 3) To pictures and character, have clear, exquisite and real display effect of a led sign.

 4) Big viewing angle to the horizontal line and vertical line, can see at every angle at this range, no picture change, no color excursion.

 5) Can repair each led lamps, so the cost of maintenance is lower and easy to repair for led sign.!



Pixel Pitch FOD10mm
Pixel Density 10,000dos/sqm
LED Configuration 1R1G1B
Module Size 320*320mm
Module Resolution 32*32 dots
Cabinet Size 960*960mm
Cabinet Resolution 96*96dot
Brightness >5500nits
Refresh Rate >1920hz
Viewing Distance 10-100m
Power Input AC110V - 220V ±15%, 50HZ
Max Power Consumption 720W/sqm
Ave. Power Consumptio 280W/sqm
Working Temperature -20℃ - +60℃
Lifespan >100,000 Hours
Operating Humidity 10% - 95%
Input Source All Format (AVI, MPEG,VOB, RM, etc)



 >> Description


 1. Usage : Outdoor , hotel, shopping mall, 4s stroes, etc.


 2. Installation : Wall-mounted, standing on floor. etc, front service most used for wall-mounted.

 3. Control : Contolled by your computer ,own equipment.; or adopt wireless controller.

 4. Connection : Connected to your computer or own equipment.

 5. Maintenance: Enough Free spare parts for replacement, front service easier to change.



 >> After Sales Service


 1. 1  years warranty.

 2. 24/7 hours online Support.

 3. Free factory training.



 4. Lifetime free repair and technical support.
