Product Details
Place of Origin: China
Brand Name: DDW
Certification: CE/ROHS/FCC/UL/ISO/3C
Payment & Shipping Terms
Minimum Order Quantity: Negotiable
Price: Negotiable
Delivery Time: 7-20 days
Payment Terms: Bank T/T transfer, Western Union
Supply Ability: 6000sqm/month
Pixel Pitch: |
1.25mm |
Moduel Size(L×W)mm: |
2.604mm |
Brightness: |
600-800CD/m2 |
Grayscale: |
65536level |
Lifespan: |
100000hrs At 50%brightness |
Service: |
Back |
Pixel Pitch: |
1.25mm |
Moduel Size(L×W)mm: |
2.604mm |
Brightness: |
600-800CD/m2 |
Grayscale: |
65536level |
Lifespan: |
100000hrs At 50%brightness |
Service: |
Back |
HD Advertising 3840Hz P1.25 Indoor Full Color LED Display Stage Video Wall Display
About Our Product:
1.Indoor p1.25 smd led display module is manufactured by using best quality material.
2.High refresh rate without flicker and distortion.
3.The final products are supreme quality and offers best outputs.
4.Light weight and easy to install
5.Single-lamp maintenance with low cost.
| P1.25 Indoor Full color LED Display Specification | ||||||||||||
| NO: | Product Name | Specification | ||||||||||
| 1 | Pixel Pitch | 1.25 mm | ||||||||||
| 2 | Pixel Configuration | 1R1G1B/SMD1010 Black lamp | ||||||||||
| 3 | Density | 640,000 pixel/m2 | ||||||||||
| 4 | Moduel Size(L×W)mm | 200mm×150mm×8mm | ||||||||||
| 5 | Cabinet Size(L×W×H)mm | 400mm×300mm×60mm | ||||||||||
| 6 | Module Resolution | 160×120 | ||||||||||
| 7 | Cabinet Resolution | 320×240 | ||||||||||
| 8 | Driving Method | 1/30 Scan | ||||||||||
| 9 | Driving IC | MBI5153/ICN 2153/FM6353 | ||||||||||
| 10 | Brightness | 600-800CD/㎡ | ||||||||||
| 11 | Contrast | 4000 :1 | ||||||||||
| 12 | Brightness Adjustment | Auto and Manual | ||||||||||
| 13 | Power Consumption | Max Power:＜900W | ||||||||||
| 14 | Average power: ＜100-300W | |||||||||||
| 15 | Cabinet Weight | 4.2kg | ||||||||||
| 16 | Color Temperature | 2000K—9500K | ||||||||||
| 17 | Horizontal Viewing Angle | 140º | ||||||||||
| 18 | Vertical Viewing Angle | 140º | ||||||||||
| 19 | Signal Processing | 16bit | ||||||||||
| 20 | Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| 21 | Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| 22 | Frame Frequency | 65 Hz | ||||||||||
| 23 | Refresh Rate | >3840Hz | ||||||||||
| 24 | Control Mode | Synchronous/Asynchronous | ||||||||||
| 25 | The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| 26 | Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| 27 | MTBF | >50000 hours | ||||||||||
| 28 | Life Span | 100,000 Hours | ||||||||||
| 29 | Operating Temperature | Working : -10 - 60 ℃ | ||||||||||
| 30 | Storage : -40 - 85 ℃ | |||||||||||
| 31 | Environment Temperature | -10℃ to 60℃; humidity Rh10% to 90% | ||||||||||
| 32 | Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| 33 | Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| 34 | Operating System Platform | WindowsXP/7/8/10 | ||||||||||
| 35 | Power Supply | AC110-240V / 5V60Hz | ||||||||||
| 36 | Protection Level | IP 45 | ||||||||||
