Product Details
Place of Origin: CHINA
Brand Name: DDW
Certification: CE,ROHS
Model Number: OES6
Payment & Shipping Terms
Minimum Order Quantity: 1square meter
Price: Negotiable
Delivery Time: 7-20 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000 sqm per month
Application: |
Indoor Advertising |
Panel Size: |
500*500/500*1000mm |
Certificate: |
CE ROHS CCC FCC ISO9001 |
Product Name: |
P3.91 Indoor LED Module |
Brightness: |
1500 |
LED Chip: |
San'an |
Application: |
Indoor Advertising |
Panel Size: |
500*500/500*1000mm |
Certificate: |
CE ROHS CCC FCC ISO9001 |
Product Name: |
P3.91 Indoor LED Module |
Brightness: |
1500 |
LED Chip: |
San'an |
Stage Hanging P3.91 1500nits Rental Led Video Wall SMD2121
MC Series led screen, which contains P1.9, P2.84, P3.9, can be used as indoor fixed led display. It can show exquisite and excellent images, can be both front and back serviceable. Besides, MC series is safe and stable, convenient and cost-effective. It is definitely your wise and worry-free choice.
1.Wireless and Modular Design, Safe and Reliable
Display, receiver and driver are integrated, simplified the internal structure. The connector of power and signal is modular design, using pin header, connected with the driving board directly. Inside of the cabinet is wireless, which has greatly improved the stability and security. Furthermore, the Fire Resistance rate of cabinet is V-0 Grade.
2.Effectively Reduce the Electromagnetic Radiation , Excellent Displays
The EMC certified cabinet with unique circuit and program design is adopted,the signal interference and system electromagnetic radiation is reduced effectively, the showing effect is more stable and worry-free.
Module Parameter:
| Pixel pitch | 3.91mm |
| Pixel configuration | 1R1G1B |
| LED type | 3-in-1 SMD2121 |
| Module size | 250x250mm |
| Module resolution | 64x64dots |
| Module quantity per cabinet | 4pcs |
Cabinet Parameter:
| Cabinet size | 500x500mm |
| Cabinet material | die- casting aluminum |
| Cabinet weight | 6.5kg |
| Cabinet resolution | 128x128 dots |
| Ingress protection | Front/Rear IP65/IP54 |
Whole Screen Parameter
| Pixel density | 65410dots/m² |
| Brightness | ≥1200 cd/m² |
| Viewing angle | H≥120° V≥120° |
| Min.viewing distance | 3.9m |
| Max.power consumption | 850W/m² |
| Avg.power consumption | 280 W/m² |
| Working voltage | 110~220VAC±15% |
| Interface | HUB75 |
| Colors | 16.7millon colors |
| Gray level | 65536 |
| Refresh rate | ≥1920Hz |
| MTBF | ≥100,000 hours |
| Lifespan | ≥100,000 hours |
| Operating temperature | -10℃ ~ +60℃ |
| Storage temperature | -20℃ ~ +60℃ |
Control System Parameter:
| Video signal (with video processor) | AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP |
| Color temperature | Adjustable by software |
| Brightness level | 256 levels, automatic adjustment by software |
| Control way | Computer, video-synchronous, real-time, off-line, internet etc. |
