Shenzhen DDW Technology Co., Ltd. info@ddwled.com 86-180-07555858
Product Details
Place of Origin: China
Brand Name: DDW
Certification: CE ROHS
Model Number: P5
Payment & Shipping Terms
Minimum Order Quantity: 1square meter
Price: Negotiable
Delivery Time: 7-20 days
Payment Terms: Bank T/T transfer, Western Union
Supply Ability: 6000sqm/month
Pixel: |
4mm |
Usage: |
Outdoor,Indoor |
Brightness: |
5500cd/m2 |
Pixel Resolution: |
64dots(W)*32dots(H) |
Refresh Frequency: |
≥1920HZ |
Warranty: |
2years |
Pixel: |
4mm |
Usage: |
Outdoor,Indoor |
Brightness: |
5500cd/m2 |
Pixel Resolution: |
64dots(W)*32dots(H) |
Refresh Frequency: |
≥1920HZ |
Warranty: |
2years |
Epistar Chip Outdoor Flexible Led Screen Panel P2 P2.5 P3 P4 Iron / Aluminum Cabinet
| Pixel Pitch | 5mm | Pixel Density | 40000 pixels/m² |
| Pixels Per Panel | 64×32Dots | Module Size | W 320mm×H 160mm |
| Weight | 0.12 kg/piece | Drive mode | 16-bit constant current drive |
| Scan Mode | 1/16S | LED Type | SMD |
| LED Configuration | 1Red,1Green,1Blue | Brightness | 800cd/m² |
| Area | 0.0512 m² | Recommended Viewing Distance | ≥5m |
| Environment | Indoor | Operating Temperature | -20℃~+60℃ |
| Storage Temperature | -40℃~+80℃ | Gap Between Modules | Seamless |
| Horizontal Viewing Angle | +/-120° | Vertical Viewing Angle | +/-120° |
| Video Frame Rate | 50/60 Hz | Rate Refresh | ≥1920 Hz |
| Color Temperature | 9000±500K | Input Power <Max> | 25W/ panel |
| LED Life Time | ≥100,000 Hours | Acoustic Noise | Fanless operation |
DDW as a national High tech enterprise, is specialized in the R&D, production, and distribution of LED display. Melton is committed to providing the market with rental series LED display, indoor & outdoor advertising LED displays, small pixel pitch HD LED screens,sports stadium LED displays, LED traffic signs and customized size LED displays.
Just as there are many applications and projects, also haymultitud LED screens. When purchasing an LED screen is not only necessary to demand a higher quality and reliability parameters, but also the characteristics of the screen to adapt to the needs of the project or application. Eachinled has specialized personnel to advise in the selection and display configuration parameters LED.
